Mid-Travel 05-23 Tacoma Leaf Springs
Introducing the DRT spec leaf springs made by Atlas in the USA
This isn't your average Tacoma leaf spring, the ONLY spring over leafs for your Tacoma capable of 14"+ travel.
Specifically designed for 2005-2023 Tacomas. These leaf springs come in three options to suit your specific needs:
Stage 1 for 0-350lbs
Stage 2 for 350-700lbs
Stage 3 for 700-1000lbs.
Lift height: 2 1/8" - 1 1/2"
9-10 leaf design.
Stage 1 and Stage 2 are the only spring over leaf springs on the market capable of an impressive 14.5” of travel, while Stage 3 offers 12” of travel. Whether you have a light setup with minimal gear or heavy-duty accessories like a HC rear bumper or camper shell, there is a leaf spring option for you.
With a smooth rate progressive design, these leaf springs provide a smooth increase in spring rate throughout the travel, reducing harshness on small bumps. The four spring retainers help keep the leafs from fanning, with the closest retainer flipped upside down for frame to leaf clearance at bump. This allows for increased bump travel when doing a shock relocation.
Designed for performance, these leaf springs are ideal for both rock crawling and prerunning driving styles.
Lift height is dependent on where you sit in the range of each stage leaf, with a general lift height of 2 1/8 - 1.5”. Make the most of your Tacoma's suspension with the DRT x Atlas leaf springs
Key points:
- Specifically designed for 2005-2023 Tacomas
- Available in three options: Stage 1 (0-350lbs), Stage 2 (350-700lbs), and Stage 3 (700-1000lbs)
- Stage 1 and Stage 2 offer 14.5” of travel, while Stage 3 offers 12” of travel
- Smooth rate progressive design for a smooth increase in spring rate throughout travel
- Four spring retainers to prevent leaf fanning, with one retainer flipped upside down for frame to leaf clearance at bump
- Capable of 2.5” negative arch at bump
- Ideal for both rock crawling and prerunning driving styles
- Includes energy suspension poly bushings
- MADE IN THE USA
